CNC system SIEMENS 828D, GSK, KND have been developed, can choose.
The system adopts mac-machine interchange mode, does not need to edit tedious procedures,convenient operation, simple,simple,fast.
Suitable for straight tooth, helical tooth,drum tooth, cone tooth, turbine, synchronous belt pulley, sprocket geat processing.
Special products can be customized according to customer requirements.
| Name | Y3150CNC4 | Y3180CNC4 |
|---|---|---|
| Max.Working Diameter | 500mm | 800mm |
| Max.working Module | M8 | M10 |
| Working Width Max. | 250mm | 300mm |
| Max.Installation Length of WorkPiece | 300mm | 350mm |
| Min.number of teth processed |
|
|
| Max.Diameter of Hob | 160mm | 180mm |
| Length of Channeling Knife of Hob | 50mm | 50m |
| Spindle Diameter of Hob |
Φ27mm 1 set of standard arbor |
Φ27mm 1 set of standard arbor |
| Speed of Main Shaft of Hob | 600r/min | 600r/min |
| Max.Rev og Operating Platform | 21.2r/min | 21.2r/min |
| Z Axle Quick Movement | 4000mm/min | 4000mm/min |
| X Axle Quick Movement | 4000mm/min | 4000mm/min |
| Distance Between Core of Hob to Core of Operation Platform | Max 450mm Min 25mm | Max 450mm Min 35mm |
| Swicel Angle of Cutter Frame | ±45° | ±45° |
| Total Capacity of Motor About | 30kw | 30kw |
| Machine Dimensions(Length×Width×Height) | 3793×2085×2460mm | 3793×2085×2460mm |
| Host weight | 8t | 9t |
