The weight ofthe main machineis up to 10T,which fuly guarantees the machine toolStability and rigidity.
The main shaft is standard equipped with BT40 high rigidity 150-diameter spindle, and is equipped with two cooling methods of central water outlet and main shaft ring spray. Both internal and external cooling can fully cool the tool, improve the processing efficiency and improve the tool life.
Standard equipped with 24 manipulator knife library. X, Y, Z axis use heavy-duty roller linear guide rail,Strong rigidity, fast moving speed.
| Name | Units | GDCQ1213 |
|---|---|---|
| Size of worktable(length x width) | mm | 1300x1000 |
| The spacing between the two columns | mm | 1200 |
| Processing range X axis | mm | 1300 |
| Y axis of processing range | mm | 1200 |
| Processing range Z axis | mm | 800 |
| Maximum distance from spindle end face to table | mm | 1200 |
| Minimum distance between spindle end face and table | mm | 400 |
| The spindle type | mm | BT40-150 |
| Knife library | Taiwan Okada | 24 tool magazines |
| X axis repeat positioning | mm | 0.005/300 |
| The Y axis is positioned repeatedly | mm | 0.005/300 |
| Z-axis repeated positioning | mm | 0.01/300 |
| Machine Dimensions (Length ×Width x Height) | mm | 4174×3275x3400 |
| Host weight | t | Approx. 11 |
