VTC Series High-Speed Vertical Lathes

X and Z axes utilize roller-type linear guideways

X and Z axes feature a cross-slide configuration, offering high travel speeds, excellent rigidity, and structural stability

The spindle employs an independent unit-style design

Phone +86 15031917770
+86 13784890302
0086319-7585050

Email shuangjia@huayuemachine.cn
jiahui@huayuemachine.cn

The VTC series of high-speed vertical lathes are high-speed CNC machine tools capable of performing turning operations that replace grinding. They are designed for machining internal and external cylindrical surfaces, conical surfaces, end faces, grooves, and chamfers. They are particularly well-suited for processing components such as automotive brake drums, wheel hubs, clutch housings, motor casings, flywheel housings, and parts for new energy vehicles.

Standard Configuration:

★ KND control system

★ 4-station live (driven) tool turret

★ Chain-plate chip conveyor

Optional Configuration:

★ Siemens 828D

★ FANUC Series 0i-TF Plus system

★ Linear scale
