CNC Vertical lathe series

Table guide rail adopts high precision rolling bearing,radial high precision double row short cylindrical roller bearing,axial high precision thrust ball bearing as rolling guide rail,axial plus pre-load,thus improving the rotation accuracy and bearing capacity of the table.

Spindle motor adopts servo main motor,speed change,no manual shift,easy to operate.

Sleeper 8 contact surface,400*225 section,turning strength,high stability.

Suitable for:high speed steel and hard alloy tools,black metal,metal and some non-metal parts of the rough,finish machining,can be used for internal and external cylindrical surface,internal and external conical surface,arc,inch thread and various complex shape of the transition surface high-speed turning.Suitable for heavy parts processing,wind power generation,automobile manufacturing and other industries.

Phone +86 15031917770
+86 13784890302
0086319-7585050

Email shuangjia@huayuemachine.cn
jiahui@huayuemachine.cn

Name	Units	SCK5117	SCK5123	SCK5128
Max.shaved eight	mm	φ1700	φ2300	φ2800
Dia.Of operating platform	mm	φ1400	φ2000	φ2400
Max.Workpiece height	mm	1200/1600	1200/1600	1200/1600
Max.weight of workpiece	T	5	10	15
Range of speed of opera rating platfom	r/min	5-130	5-100	5-90
Stage speed stage		Stepless	Stepless	Stepless
Vertical stroke of vertical tool post	mm	-140-1030	-155-1365	-155-1615
Vertical tol post ram stroke	mm	800	800	800
Rapid movement speed of too post(x,Z axis)	mm/min	3000	3000	3000
Number of knife holders	indivual	1	1	1
Beam vertical stroke	mm	800/1200	800/1200	800/1200
Beam fting speed	mm/min	500	500	500
Vertical turetram sectin	mm × mm	400×225	400×225	400×225
CNC system(Optional)	Standard	KND	KND	KND
Machine Dimenions (Length ×With×Height without protection)	mm	6100×3500x4509	7600x4800x5300	7600x4800x5300
Host weight	kg	18000	25200	33000
